Step1: Product
NXP USA Inc. SGTL5000XNBA3
Images are for reference only
Manufacturer
Manufacturer No
SGTL5000XNBA3
Date Code
25+
Quantity
980
Availability
In Stock
Package
-
Packaging
Tray
Description
IC AUDIO CODEC STEREO 32HVQFN
Detailed Description
Stereo Audio Interface I2C, I2S, PCM, SPI
Datasheet
Payment
Delivery
Type
Stereo Audio
Series
-
Packaging
Tray
Sigma Delta
No
Manufacturer
NXP USA Inc.
Mounting Type
-
Data Interface
I2C, I2S, PCM, SPI
Package / Case
-
Resolution (Bits)
-
Number of ADCs / DACs
1 / 1
Operating Temperature
-40°C ~ 85°C (TA)
Supplier Device Package
-
Voltage - Supply, Analog
1.62V ~ 3.6V
Voltage - Supply, Digital
1.1V ~ 2V, 1.62V ~ 3.6V
S/N Ratio, ADCs / DACs (db) Typ
90 / 100
Dynamic Range, ADCs / DACs (db) Typ
87 / 100
| Attribute | Value |
|---|---|
| Type | Stereo Audio |
| Series | - |
| Packaging | Tray |
| Sigma Delta | No |
| Manufacturer | NXP USA Inc. |
| Mounting Type | - |
| Data Interface | I2C, I2S, PCM, SPI |
| Package / Case | - |
| Resolution (Bits) | - |
| Number of ADCs / DACs | 1 / 1 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Supplier Device Package | - |
| Voltage - Supply, Analog | 1.62V ~ 3.6V |
| Voltage - Supply, Digital | 1.1V ~ 2V, 1.62V ~ 3.6V |
| S/N Ratio, ADCs / DACs (db) Typ | 90 / 100 |
| Dynamic Range, ADCs / DACs (db) Typ | 87 / 100 |
