NXP Semiconductors NX7002BKMBYL
Images are for reference only
Manufacturer
Manufacturer No
NX7002BKMBYL
Date Code
25+
Quantity
1,500
Availability
In Stock
Package
3-XFDFN
Packaging
Bulk
Description
NEXPERIA NX7002B - 60V, N-CHANNE
Detailed Description
N-Channel 60 V 350mA (Ta) 350mW (Ta), 3.1W (Tc) Surface Mount DFN1006B-3
Datasheet
Payment
Delivery
Mfr
NXP Semiconductors
Grade
-
Series
TrenchMOS™
FET Type
N-Channel
Packaging
Bulk
Vgs (Max)
±20V
Technology
MOSFET (Metal Oxide)
FET Feature
-
Mounting Type
Surface Mount
Qualification
-
Package / Case
3-XFDFN
Vgs(th) (Max) @ Id
2.1V @ 250µA
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
2.8Ohm @ 200mA, 10V
Power Dissipation (Max)
350mW (Ta), 3.1W (Tc)
Supplier Device Package
DFN1006B-3
Gate Charge (Qg) (Max) @ Vgs
1 nC @ 10 V
Drain to Source Voltage (Vdss)
60 V
Input Capacitance (Ciss) (Max) @ Vds
23.6 pF @ 10 V
Drive Voltage (Max Rds On, Min Rds On)
5V, 10V
Current - Continuous Drain (Id) @ 25°C
350mA (Ta)
| Attribute | Value |
|---|---|
| Mfr | NXP Semiconductors |
| Grade | - |
| Series | TrenchMOS™ |
| FET Type | N-Channel |
| Packaging | Bulk |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 3-XFDFN |
| Vgs(th) (Max) @ Id | 2.1V @ 250µA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 2.8Ohm @ 200mA, 10V |
| Power Dissipation (Max) | 350mW (Ta), 3.1W (Tc) |
| Supplier Device Package | DFN1006B-3 |
| Gate Charge (Qg) (Max) @ Vgs | 1 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 60 V |
| Input Capacitance (Ciss) (Max) @ Vds | 23.6 pF @ 10 V |
| Drive Voltage (Max Rds On, Min Rds On) | 5V, 10V |
| Current - Continuous Drain (Id) @ 25°C | 350mA (Ta) |
