Step1: Product
NKK Switches IS15SBFP4B
Images are for reference only
Manufacturer
Manufacturer No
IS15SBFP4B
Packaging
Tray
Description
IS LCD 36x24 BW COMPACT
Detailed Description
Programmable Display Switch Pushbutton, LCD SPST-NO 0.1A @ 12VDC Through Hole
Datasheet
Payment
Delivery
Type
Pushbutton, LCD
Style
Compact
Series
SmartDisplay™
Circuit
SPST-NO
Face Size
19.0mm L x 18.0mm W
LED Color
White, Super Bright
Packaging
Tray
Display Mode
Black and White, FSTN Positive
Manufacturer
NKK Switches
Pixel Format
36 x 24
Travel Range
1.8mm
Viewing Area
13.0mm L x 10.7mm W
Mounting Type
Through Hole
Supply Voltage
3.0 ~ 5.5VDC
Operating Force
224gf
Switch Function
Off-Mom
Termination Style
PC Pin
LED Forward Current
20mA
LED Forward Voltage
3.6VDC
Operating Temperature
0°C ~ 40°C
Contact Rating @ Voltage
0.1A @ 12VDC
| Attribute | Value |
|---|---|
| Type | Pushbutton, LCD |
| Style | Compact |
| Series | SmartDisplay™ |
| Circuit | SPST-NO |
| Face Size | 19.0mm L x 18.0mm W |
| LED Color | White, Super Bright |
| Packaging | Tray |
| Display Mode | Black and White, FSTN Positive |
| Manufacturer | NKK Switches |
| Pixel Format | 36 x 24 |
| Travel Range | 1.8mm |
| Viewing Area | 13.0mm L x 10.7mm W |
| Mounting Type | Through Hole |
| Supply Voltage | 3.0 ~ 5.5VDC |
| Operating Force | 224gf |
| Switch Function | Off-Mom |
| Termination Style | PC Pin |
| LED Forward Current | 20mA |
| LED Forward Voltage | 3.6VDC |
| Operating Temperature | 0°C ~ 40°C |
| Contact Rating @ Voltage | 0.1A @ 12VDC |
