Step1: Product
Neutrik Americas, Inc. NF2D-B-9
Images are for reference only
Manufacturer
Manufacturer No
NF2D-B-9
Packaging
Box
Description
JACKS RCA D SERIES STYLE -WHITE-
Detailed Description
Phono (RCA) Jack Mono Connector Solder Cup, Solder
Datasheet
Payment
Delivery
Mfr
Neutrik Americas, Inc.
Grade
-
Gender
Female
Series
B
Features
-
Includes
-
Packaging
Box
Shielding
Unshielded
Body Color
Black
Termination
Solder Cup, Solder
Thread Size
-
Signal Lines
Mono
Body Material
-
Cable Opening
-
Mounting Type
Panel Mount
Qualification
-
Connector Type
Phono (RCA) Jack
Actual Diameter
-
Panel Hole Size
0.929" (23.60mm)
Voltage - Rated
50V
Contact Material
Brass
Housing Material
-
Insulation Color
White
Internal Switch(s)
Does Not Contain Switch
Mating Length/Depth
-
Current Rating (Amps)
16 A
Operating Temperature
-30°C ~ 80°C
Contact Material - Plating
Gold
Number of Positions/Contacts
2 Conductors, 2 Contacts
Industry Recognized Mating Diameter
-
| Attribute | Value |
|---|---|
| Mfr | Neutrik Americas, Inc. |
| Grade | - |
| Gender | Female |
| Series | B |
| Features | - |
| Includes | - |
| Packaging | Box |
| Shielding | Unshielded |
| Body Color | Black |
| Termination | Solder Cup, Solder |
| Thread Size | - |
| Signal Lines | Mono |
| Body Material | - |
| Cable Opening | - |
| Mounting Type | Panel Mount |
| Qualification | - |
| Connector Type | Phono (RCA) Jack |
| Actual Diameter | - |
| Panel Hole Size | 0.929" (23.60mm) |
| Voltage - Rated | 50V |
| Contact Material | Brass |
| Housing Material | - |
| Insulation Color | White |
| Internal Switch(s) | Does Not Contain Switch |
| Mating Length/Depth | - |
| Current Rating (Amps) | 16 A |
| Operating Temperature | -30°C ~ 80°C |
| Contact Material - Plating | Gold |
| Number of Positions/Contacts | 2 Conductors, 2 Contacts |
| Industry Recognized Mating Diameter | - |
