Step1: Product
NEC Corporation 2SK3058-Z-E1-AZ
Images are for reference only
Manufacturer
Manufacturer No
2SK3058-Z-E1-AZ
Package
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Packaging
Bulk
Description
N-CHANNEL POWER MOSFET
Detailed Description
N-Channel 60 V 55A 1.5W Surface Mount TO-263, TO-220SMD
Datasheet
Payment
Delivery
Mfr
NEC Corporation
Grade
-
Series
-
FET Type
N-Channel
Packaging
Bulk
Vgs (Max)
20V
Technology
MOSFET (Metal Oxide)
FET Feature
-
Mounting Type
Surface Mount
Qualification
-
Package / Case
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Vgs(th) (Max) @ Id
2V @ 1mA
Operating Temperature
-55°C ~ 150°C
Rds On (Max) @ Id, Vgs
17mOhm @ 28A, 10V
Power Dissipation (Max)
1.5W
Supplier Device Package
TO-263, TO-220SMD
Gate Charge (Qg) (Max) @ Vgs
45 nC @ 10 V
Drain to Source Voltage (Vdss)
60 V
Input Capacitance (Ciss) (Max) @ Vds
2100 pF @ 10 V
Drive Voltage (Max Rds On, Min Rds On)
4V, 10V
Current - Continuous Drain (Id) @ 25°C
55A
| Attribute | Value |
|---|---|
| Mfr | NEC Corporation |
| Grade | - |
| Series | - |
| FET Type | N-Channel |
| Packaging | Bulk |
| Vgs (Max) | 20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Vgs(th) (Max) @ Id | 2V @ 1mA |
| Operating Temperature | -55°C ~ 150°C |
| Rds On (Max) @ Id, Vgs | 17mOhm @ 28A, 10V |
| Power Dissipation (Max) | 1.5W |
| Supplier Device Package | TO-263, TO-220SMD |
| Gate Charge (Qg) (Max) @ Vgs | 45 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 60 V |
| Input Capacitance (Ciss) (Max) @ Vds | 2100 pF @ 10 V |
| Drive Voltage (Max Rds On, Min Rds On) | 4V, 10V |
| Current - Continuous Drain (Id) @ 25°C | 55A |
