National Semiconductor LM2630MTCX-ADJ
Images are for reference only
Manufacturer
Manufacturer No
LM2630MTCX-ADJ
Availability
In Stock
Package
20-TSSOP (0.173", 4.40mm Width)
Packaging
Bulk
Description
SWITCHING CONTROLLER
Detailed Description
Buck Regulator Positive Output Step-Down DC-DC Controller IC 20-TSSOP
Datasheet
Payment
Delivery
Series
-
Function
Step-Down
Topology
Buck
Packaging
Bulk
Clock Sync
Yes
Output Type
Transistor Driver
Manufacturer
National Semiconductor
Mounting Type
Surface Mount
Output Phases
1
Package / Case
20-TSSOP (0.173", 4.40mm Width)
Control Features
Current Limit, Dead Time Control, Enable, Frequency Control, Power Good, Soft Start
Duty Cycle (Max)
96%
Number of Outputs
2
Serial Interfaces
-
Base Product Number
LM2630
Output Configuration
Positive
Frequency - Switching
200kHz ~ 400kHz
Operating Temperature
-40°C ~ 125°C (TJ)
Synchronous Rectifier
Yes
Supplier Device Package
20-TSSOP
Voltage - Supply (Vcc/Vdd)
4.5V ~ 30V
| Attribute | Value |
|---|---|
| Series | - |
| Function | Step-Down |
| Topology | Buck |
| Packaging | Bulk |
| Clock Sync | Yes |
| Output Type | Transistor Driver |
| Manufacturer | National Semiconductor |
| Mounting Type | Surface Mount |
| Output Phases | 1 |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) |
| Control Features | Current Limit, Dead Time Control, Enable, Frequency Control, Power Good, Soft Start |
| Duty Cycle (Max) | 96% |
| Number of Outputs | 2 |
| Serial Interfaces | - |
| Base Product Number | LM2630 |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz ~ 400kHz |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Synchronous Rectifier | Yes |
| Supplier Device Package | 20-TSSOP |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 30V |
