Step1: Product
Monolithic Power Systems Inc. MA700GQ-Z
Images are for reference only
Manufacturer
Manufacturer No
MA700GQ-Z
Date Code
1722
Quantity
16,389
Availability
In Stock
Package
16-VFQFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
SENSOR ANGLE SMD
Detailed Description
Hall Effect Sensor Angle External Magnet, Not Included SMD (SMT) Tab
Payment
Delivery
Output
SPI
Series
-
Linearity
-
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
Hall Effect
Linear Range
-
Manufacturer
Monolithic Power Systems Inc.
Actuator Type
External Magnet, Not Included
For Measuring
Angle
Mounting Type
Surface Mount
Output Signal
-
Package / Case
16-VFQFN Exposed Pad
Voltage - Supply
3V ~ 3.6V
Termination Style
SMD (SMT) Tab
Base Product Number
MA700
DigiKey Programmable
-
Resistance Tolerance
-
Operating Temperature
-40°C ~ 125°C
Supplier Device Package
16-QFN (3x3)
Rotation Angle - Electrical, Mechanical
-
| Attribute | Value |
|---|---|
| Output | SPI |
| Series | - |
| Linearity | - |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | Hall Effect |
| Linear Range | - |
| Manufacturer | Monolithic Power Systems Inc. |
| Actuator Type | External Magnet, Not Included |
| For Measuring | Angle |
| Mounting Type | Surface Mount |
| Output Signal | - |
| Package / Case | 16-VFQFN Exposed Pad |
| Voltage - Supply | 3V ~ 3.6V |
| Termination Style | SMD (SMT) Tab |
| Base Product Number | MA700 |
| DigiKey Programmable | - |
| Resistance Tolerance | - |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | 16-QFN (3x3) |
| Rotation Angle - Electrical, Mechanical | - |
