Molex MM-222-025-213-4100
Images are for reference only
Manufacturer
Manufacturer No
MM-222-025-213-4100
Availability
In Stock
Packaging
Bulk
Description
CONN MICRO-D RCPT 25POS SLDR CUP
Detailed Description
25 Position D-Type, Micro-D Receptacle, Female Sockets Connector
Datasheet
Payment
Delivery
Mfr
Molex
Color
-
Series
M
Features
-
Packaging
Bulk
Wire Gauge
-
Termination
Solder Cup
Contact Form
-
Contact Type
Signal
Mounting Type
Free Hanging (In-Line)
Connector Type
Receptacle, Female Sockets
Contact Finish
Gold
Flange Feature
Mating Side, Female Screwlock (2-56)
Number of Rows
2
Voltage Rating
-
Backset Spacing
-
Connector Style
D-Type, Micro-D
Contact Material
Brass
Primary Material
Metal
Ingress Protection
-
Dielectric Material
Polyphenylene Sulfide (PPS)
Number of Positions
25
Current Rating (Amps)
3A
Operating Temperature
-55°C ~ 125°C
Shell Material, Finish
Aluminum Alloy, Nickel Plated, Electroless
Contact Finish Thickness
50.0µin (1.27µm)
Material Flammability Rating
-
Shell Size, Connector Layout
0.050 Pitch x 0.050 Row to Row
| Attribute | Value |
|---|---|
| Mfr | Molex |
| Color | - |
| Series | M |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | - |
| Termination | Solder Cup |
| Contact Form | - |
| Contact Type | Signal |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Mating Side, Female Screwlock (2-56) |
| Number of Rows | 2 |
| Voltage Rating | - |
| Backset Spacing | - |
| Connector Style | D-Type, Micro-D |
| Contact Material | Brass |
| Primary Material | Metal |
| Ingress Protection | - |
| Dielectric Material | Polyphenylene Sulfide (PPS) |
| Number of Positions | 25 |
| Current Rating (Amps) | 3A |
| Operating Temperature | -55°C ~ 125°C |
| Shell Material, Finish | Aluminum Alloy, Nickel Plated, Electroless |
| Contact Finish Thickness | 50.0µin (1.27µm) |
| Material Flammability Rating | - |
| Shell Size, Connector Layout | 0.050 Pitch x 0.050 Row to Row |
