Step1: Product
Mill-Max Manufacturing Corp. 110-83-318-41-001000
Images are for reference only
Manufacturer
Manufacturer No
110-83-318-41-001000
Packaging
Tube
Description
STANDRD SOLDER TAIL DIP SOCKET
Detailed Description
18 Pos DIP, 0.3" (7.62mm) Row Spacing Socket Gold Through Hole
Datasheet
Payment
Delivery
Type
DIP, 0.3" (7.62mm) Row Spacing
Series
110
Features
Open Frame
Packaging
Tube
Termination
Solder
Manufacturer
Mill-Max Manufacturing Corp.
Pitch - Post
0.100" (2.54mm)
Mounting Type
Through Hole
Pitch - Mating
0.100" (2.54mm)
Housing Material
Thermoplastic
Contact Resistance
10mOhm
Contact Finish - Post
Gold
Current Rating (Amps)
3 A
Operating Temperature
-55°C ~ 125°C
Contact Finish - Mating
Gold
Contact Material - Post
Brass
Termination Post Length
0.125" (3.18mm)
Contact Material - Mating
Beryllium Copper
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
30.0µin (0.76µm)
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Number of Positions or Pins (Grid)
18
| Attribute | Value |
|---|---|
| Type | DIP, 0.3" (7.62mm) Row Spacing |
| Series | 110 |
| Features | Open Frame |
| Packaging | Tube |
| Termination | Solder |
| Manufacturer | Mill-Max Manufacturing Corp. |
| Pitch - Post | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Pitch - Mating | 0.100" (2.54mm) |
| Housing Material | Thermoplastic |
| Contact Resistance | 10mOhm |
| Contact Finish - Post | Gold |
| Current Rating (Amps) | 3 A |
| Operating Temperature | -55°C ~ 125°C |
| Contact Finish - Mating | Gold |
| Contact Material - Post | Brass |
| Termination Post Length | 0.125" (3.18mm) |
| Contact Material - Mating | Beryllium Copper |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | 30.0µin (0.76µm) |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Number of Positions or Pins (Grid) | 18 |
