Midori Precisions by Nidec Components CP36US1-Z00-A

Images are for reference only

Manufacturer

Midori Precisions by Nidec Components

Manufacturer No

CP36US1-Z00-A

Package

Module, Round Shaft

Packaging

Box

Description

POTENTIOMETER, ELECTRICAL ANGLE

Detailed Description

Magnetoresistive Sensor Angle Round Shaft Cable

Datasheet

CP36US1-Z00-A

Payment

Delivery

Grade

-

Output

Analog Current

Series

CP36U

Linearity

±0.2%

Packaging

Box

Resistance

600 Ohms

Technology

Magnetoresistive

Linear Range

-

Manufacturer

Midori Precisions by Nidec Components

Actuator Type

Round Shaft

For Measuring

Angle

Mounting Type

Panel Mount

Output Signal

Programmable

Qualification

-

Package / Case

Module, Round Shaft

Voltage - Supply

16V ~ 32V

Termination Style

Cable

Resistance Tolerance

-

Operating Temperature

-40°C ~ 85°C

Supplier Device Package

-

Rotation Angle - Electrical, Mechanical

18° ~ 360°

Attribute	Value
Grade	-
Output	Analog Current
Series	CP36U
Linearity	±0.2%
Packaging	Box
Resistance	600 Ohms
Technology	Magnetoresistive
Linear Range	-
Manufacturer	Midori Precisions by Nidec Components
Actuator Type	Round Shaft
For Measuring	Angle
Mounting Type	Panel Mount
Output Signal	Programmable
Qualification	-
Package / Case	Module, Round Shaft
Voltage - Supply	16V ~ 32V
Termination Style	Cable
Resistance Tolerance	-
Operating Temperature	-40°C ~ 85°C
Supplier Device Package	-
Rotation Angle - Electrical, Mechanical	18° ~ 360°
