Step1: Product
Midas Displays MC21605A6W-FPTLW-V2
Images are for reference only
Manufacturer
Manufacturer No
MC21605A6W-FPTLW-V2
Availability
In Stock
Packaging
Tray
Description
2X16 CHARACTER CHIP-ON-BOARD LCD
Detailed Description
Character Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - White Parallel 84.00mm x 44.00mm x 13.50mm
Datasheet
Payment
Delivery
Series
MC21605A
Dot Size
0.56mm W x 0.61mm H
Backlight
LED - White
Interface
Parallel
Packaging
Tray
Text Color
Black
Display Mode
Transflective
Display Type
STN - Super-Twisted Nematic
Manufacturer
Midas Displays
Viewing Area
64.50mm L x 16.40mm W
Character Size
5.23mm H x 3.00mm W
Display Format
2 x 16
Controller Type
ST7066U
Background Color
White
Character Format
5 x 8 Dots
Voltage - Supply
5V
Outline L x W x H
84.00mm x 44.00mm x 13.50mm
Number of Characters
1.0
Operating Temperature
-20°C ~ 70°C
| Attribute | Value |
|---|---|
| Series | MC21605A |
| Dot Size | 0.56mm W x 0.61mm H |
| Backlight | LED - White |
| Interface | Parallel |
| Packaging | Tray |
| Text Color | Black |
| Display Mode | Transflective |
| Display Type | STN - Super-Twisted Nematic |
| Manufacturer | Midas Displays |
| Viewing Area | 64.50mm L x 16.40mm W |
| Character Size | 5.23mm H x 3.00mm W |
| Display Format | 2 x 16 |
| Controller Type | ST7066U |
| Background Color | White |
| Character Format | 5 x 8 Dots |
| Voltage - Supply | 5V |
| Outline L x W x H | 84.00mm x 44.00mm x 13.50mm |
| Number of Characters | 1.0 |
| Operating Temperature | -20°C ~ 70°C |
