Microsemi Corporation SG2845M

Images are for reference only

Manufacturer

Microsemi Corporation

Manufacturer No

SG2845M

Package

8-DIP (0.300", 7.62mm)

Packaging

Tube

Description

IC REG CTRLR FLYBACK 8DIP

Detailed Description

Flyback Regulator Positive, Isolation Capable Output Step-Up/Step-Down DC-DC Controller IC 8-DIP

Datasheet

SG2845M

Payment

Delivery

Series

-

Function

Step-Up/Step-Down

Topology

Flyback

Packaging

Tube

Clock Sync

No

Output Type

Transistor Driver

Manufacturer

Microsemi Corporation

Mounting Type

Through Hole

Output Phases

1

Package / Case

8-DIP (0.300", 7.62mm)

Control Features

-

Duty Cycle (Max)

48%

Number of Outputs

1

Serial Interfaces

-

Base Product Number

SG2845

Output Configuration

Positive, Isolation Capable

Frequency - Switching

1Hz ~ 500kHz

Operating Temperature

-25°C ~ 85°C (TA)

Synchronous Rectifier

Yes

Supplier Device Package

8-DIP

Voltage - Supply (Vcc/Vdd)

7.6V ~ 30V

Attribute	Value
Series	-
Function	Step-Up/Step-Down
Topology	Flyback
Packaging	Tube
Clock Sync	No
Output Type	Transistor Driver
Manufacturer	Microsemi Corporation
Mounting Type	Through Hole
Output Phases	1
Package / Case	8-DIP (0.300", 7.62mm)
Control Features	-
Duty Cycle (Max)	48%
Number of Outputs	1
Serial Interfaces	-
Base Product Number	SG2845
Output Configuration	Positive, Isolation Capable
Frequency - Switching	1Hz ~ 500kHz
Operating Temperature	-25°C ~ 85°C (TA)
Synchronous Rectifier	Yes
Supplier Device Package	8-DIP
Voltage - Supply (Vcc/Vdd)	7.6V ~ 30V
