Microchip Technology APT40GF120JRD
Images are for reference only
Manufacturer
Manufacturer No
APT40GF120JRD
Availability
In Stock
Package
SOT-227-4, miniBLOC
Packaging
Tube
Description
IGBT MOD 1200V 60A 390W SOT-227
Detailed Description
IGBT Module Single 1200 V 60 A 390 W Chassis Mount SOT-227 (ISOTOP®)
Datasheet
Payment
Delivery
Input
Standard
Series
-
IGBT Type
-
Packaging
Tube
Power - Max
390 W
Manufacturer
Microchip Technology
Configuration
Single
Mounting Type
Chassis Mount
NTC Thermistor
No
Package / Case
SOT-227-4, miniBLOC
Base Product Number
APT40
Operating Temperature
-55°C ~ 150°C (TJ)
Supplier Device Package
SOT-227 (ISOTOP®)
Vce(on) (Max) @ Vge, Ic
3.4V @ 15V, 50A
Current - Collector (Ic) (Max)
60 A
Input Capacitance (Cies) @ Vce
3.45 nF @ 25 V
Current - Collector Cutoff (Max)
500 µA
Voltage - Collector Emitter Breakdown (Max)
1200 V
| Attribute | Value |
|---|---|
| Input | Standard |
| Series | - |
| IGBT Type | - |
| Packaging | Tube |
| Power - Max | 390 W |
| Manufacturer | Microchip Technology |
| Configuration | Single |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | SOT-227-4, miniBLOC |
| Base Product Number | APT40 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | SOT-227 (ISOTOP®) |
| Vce(on) (Max) @ Vge, Ic | 3.4V @ 15V, 50A |
| Current - Collector (Ic) (Max) | 60 A |
| Input Capacitance (Cies) @ Vce | 3.45 nF @ 25 V |
| Current - Collector Cutoff (Max) | 500 µA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
