Step1: Product
Maanshan New Conda Magnetic Industrial Co.,Ltd. UU100/75/30-LP9
Images are for reference only
Manufacturer
Manufacturer No
UU100/75/30-LP9
Packaging
Box
Description
FERRITE CORE U LP9 1PC
Detailed Description
Uncoated LP9 Ferrite Core U Type 3.937" (100.00mm) Length 1.181" (30.00mm) Width Diameter 2.972" (75.50mm) Height
Datasheet
Payment
Delivery
Gap
Ungapped
Width
1.181" (30.00mm)
Finish
Uncoated
Height
2.972" (75.50mm)
Length
3.937" (100.00mm)
Series
U100/75/30
Diameter
-
Material
LP9
Core Type
U
Packaging
Box
Tolerance
±25%
Manufacturer
Maanshan New Conda Magnetic Industrial Co.,Ltd.
Inductance Factor (Al)
8.5 µH
Supplier Device Package
U 100 x 75 x 30
Effective Area (Ae) mm²
917.0
Effective Length (le) mm
354.0
Initial Permeability (µi)
3300
Core Factor (ΣI/A) mm⁻¹
0.39
Effective Permeability (µe)
2613.0
Effective Magnetic Volume (Ve) mm³
324620.0
Minimum Core Cross Section (Amin) mm²
917.0
| Attribute | Value |
|---|---|
| Gap | Ungapped |
| Width | 1.181" (30.00mm) |
| Finish | Uncoated |
| Height | 2.972" (75.50mm) |
| Length | 3.937" (100.00mm) |
| Series | U100/75/30 |
| Diameter | - |
| Material | LP9 |
| Core Type | U |
| Packaging | Box |
| Tolerance | ±25% |
| Manufacturer | Maanshan New Conda Magnetic Industrial Co.,Ltd. |
| Inductance Factor (Al) | 8.5 µH |
| Supplier Device Package | U 100 x 75 x 30 |
| Effective Area (Ae) mm² | 917.0 |
| Effective Length (le) mm | 354.0 |
| Initial Permeability (µi) | 3300 |
| Core Factor (ΣI/A) mm⁻¹ | 0.39 |
| Effective Permeability (µe) | 2613.0 |
| Effective Magnetic Volume (Ve) mm³ | 324620.0 |
| Minimum Core Cross Section (Amin) mm² | 917.0 |
