Step1: Product
Keystone Electronics 11073
Images are for reference only
Manufacturer
Manufacturer No
11073
Availability
In Stock
Packaging
Bulk
Description
CONN PC PIN CIRC 0.040DIA TIN
Detailed Description
PC Pin Terminal Connector Through Hole Tin 0.040" (1.02mm) Dia
Datasheet
Payment
Delivery
Series
-
Packaging
Bulk
Insulation
Insulated
Termination
Press-Fit
Manufacturer
Keystone Electronics
Mounting Type
Through Hole
Terminal Type
PC Pin
Contact Finish
Tin
Terminal Style
Single End
Board Thickness
0.062" (1.57mm)
Flange Diameter
0.172" (4.37mm)
Contact Material
Brass
Insulation Color
White
Length - Overall
0.590" (14.99mm)
Length - Above Flange
0.450" (11.43mm)
Length - Below Flange
0.100" (2.54mm)
Material - Insulation
Polytetrafluoroethylene (PTFE)
Mounting Hole Diameter
0.136" (3.45mm)
Pin Size - Above Flange
0.040" (1.02mm) Dia
Pin Size - Below Flange
-
Contact Finish Thickness
-
| Attribute | Value |
|---|---|
| Series | - |
| Packaging | Bulk |
| Insulation | Insulated |
| Termination | Press-Fit |
| Manufacturer | Keystone Electronics |
| Mounting Type | Through Hole |
| Terminal Type | PC Pin |
| Contact Finish | Tin |
| Terminal Style | Single End |
| Board Thickness | 0.062" (1.57mm) |
| Flange Diameter | 0.172" (4.37mm) |
| Contact Material | Brass |
| Insulation Color | White |
| Length - Overall | 0.590" (14.99mm) |
| Length - Above Flange | 0.450" (11.43mm) |
| Length - Below Flange | 0.100" (2.54mm) |
| Material - Insulation | Polytetrafluoroethylene (PTFE) |
| Mounting Hole Diameter | 0.136" (3.45mm) |
| Pin Size - Above Flange | 0.040" (1.02mm) Dia |
| Pin Size - Below Flange | - |
| Contact Finish Thickness | - |
