Joymax Electronics TWX-144XSA3B
Images are for reference only
Manufacturer
Manufacturer No
TWX-144XSA3B
Packaging
Bag
Description
ANT WIFI 7/6E WHIP SMA MALE
Detailed Description
RF ANTENNA 802.11ax, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E Whip, Tilt SMA Male Connector Mount
Datasheet
Payment
Delivery
Gain
2.5dBi, 4.5dBi, 4.4dBi
VSWR
1.3, 1.6, 2.1
Grade
-
Series
144
Features
-
Packaging
Bag
Power - Max
1 W
Return Loss
-17.7dB, -12.7dB, -9dB
Termination
SMA Male
Antenna Type
Whip, Tilt
Applications
802.11ax, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E
Height (Max)
5.433" (138.00mm)
Manufacturer
Joymax Electronics
Mounting Type
Connector Mount
Qualification
-
Frequency Group
Wide Band
Frequency Range
2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz
Number of Bands
3
Ingress Protection
-
RF Family/Standard
WiFi
Frequency (Center/Band)
2.45GHz, 5.5GHz, 6.525GHz
| Attribute | Value |
|---|---|
| Gain | 2.5dBi, 4.5dBi, 4.4dBi |
| VSWR | 1.3, 1.6, 2.1 |
| Grade | - |
| Series | 144 |
| Features | - |
| Packaging | Bag |
| Power - Max | 1 W |
| Return Loss | -17.7dB, -12.7dB, -9dB |
| Termination | SMA Male |
| Antenna Type | Whip, Tilt |
| Applications | 802.11ax, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E |
| Height (Max) | 5.433" (138.00mm) |
| Manufacturer | Joymax Electronics |
| Mounting Type | Connector Mount |
| Qualification | - |
| Frequency Group | Wide Band |
| Frequency Range | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz |
| Number of Bands | 3 |
| Ingress Protection | - |
| RF Family/Standard | WiFi |
| Frequency (Center/Band) | 2.45GHz, 5.5GHz, 6.525GHz |
