International Rectifier IR2235JPBF
Images are for reference only
Manufacturer
Manufacturer No
IR2235JPBF
Quantity
4
Availability
In Stock
Package
44-LCC (J-Lead), 32 Leads
Packaging
Bulk
Description
IR2235J - GATE DRIVER
Detailed Description
Half-Bridge Gate Driver IC Inverting 44-PLCC, 32 Leads (16.58x16.58)
Datasheet
Payment
Delivery
Series
-
Gate Type
IGBT, MOSFET (N-Channel)
Packaging
Bulk
Input Type
Inverting
Channel Type
3-Phase
Manufacturer
International Rectifier
Mounting Type
Surface Mount
Package / Case
44-LCC (J-Lead), 32 Leads
Voltage - Supply
10V ~ 20V
Number of Drivers
6
Base Product Number
IR2235
DigiKey Programmable
Not Verified
Driven Configuration
Half-Bridge
Operating Temperature
125°C (TJ)
Rise / Fall Time (Typ)
90ns, 40ns
Supplier Device Package
44-PLCC, 32 Leads (16.58x16.58)
Logic Voltage - VIL, VIH
0.8V, 2V
High Side Voltage - Max (Bootstrap)
1.2 V
Current - Peak Output (Source, Sink)
250mA, 500mA
| Attribute | Value |
|---|---|
| Series | - |
| Gate Type | IGBT, MOSFET (N-Channel) |
| Packaging | Bulk |
| Input Type | Inverting |
| Channel Type | 3-Phase |
| Manufacturer | International Rectifier |
| Mounting Type | Surface Mount |
| Package / Case | 44-LCC (J-Lead), 32 Leads |
| Voltage - Supply | 10V ~ 20V |
| Number of Drivers | 6 |
| Base Product Number | IR2235 |
| DigiKey Programmable | Not Verified |
| Driven Configuration | Half-Bridge |
| Operating Temperature | 125°C (TJ) |
| Rise / Fall Time (Typ) | 90ns, 40ns |
| Supplier Device Package | 44-PLCC, 32 Leads (16.58x16.58) |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| High Side Voltage - Max (Bootstrap) | 1.2 V |
| Current - Peak Output (Source, Sink) | 250mA, 500mA |
