Step1: Product
Infineon Technologies CYW43362KUBGT
Images are for reference only
Manufacturer
Manufacturer No
CYW43362KUBGT
Quantity
20
Availability
In Stock
Package
69-UFBGA, WLBGA
Packaging
Tape & Reel (TR)
Description
IC RF TXRX+MCU WIFI 69WLBGA
Detailed Description
IC RF TxRx + MCU WiFi 802.11b/g/n 2.4GHz 69-UFBGA, WLBGA
Datasheet
Payment
Delivery
Mfr
Infineon Technologies
GPIO
5
Type
TxRx + MCU
Series
-
Protocol
802.11b/g/n
Frequency
2.4GHz
Packaging
Tape & Reel (TR)
Modulation
16QAM, 64QAM, BPSK, CCK, DSSS, QPSK, OFDM
Memory Size
448kB ROM, 240kB RAM
Sensitivity
-97dBm
Mounting Type
Surface Mount
Package / Case
69-UFBGA, WLBGA
Power - Output
18.5dBm
Data Rate (Max)
72Mbps
Voltage - Supply
1.2V ~ 3.3V
Serial Interfaces
JTAG, SPI, UART
RF Family/Standard
WiFi
Base Product Number
CYW43362
Current - Receiving
52mA ~ 59mA
DigiKey Programmable
Not Verified
Operating Temperature
-30°C ~ 85°C
Current - Transmitting
260mA ~ 320mA
Supplier Device Package
69-WLBGA (4.52x2.92)
| Attribute | Value |
|---|---|
| Mfr | Infineon Technologies |
| GPIO | 5 |
| Type | TxRx + MCU |
| Series | - |
| Protocol | 802.11b/g/n |
| Frequency | 2.4GHz |
| Packaging | Tape & Reel (TR) |
| Modulation | 16QAM, 64QAM, BPSK, CCK, DSSS, QPSK, OFDM |
| Memory Size | 448kB ROM, 240kB RAM |
| Sensitivity | -97dBm |
| Mounting Type | Surface Mount |
| Package / Case | 69-UFBGA, WLBGA |
| Power - Output | 18.5dBm |
| Data Rate (Max) | 72Mbps |
| Voltage - Supply | 1.2V ~ 3.3V |
| Serial Interfaces | JTAG, SPI, UART |
| RF Family/Standard | WiFi |
| Base Product Number | CYW43362 |
| Current - Receiving | 52mA ~ 59mA |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -30°C ~ 85°C |
| Current - Transmitting | 260mA ~ 320mA |
| Supplier Device Package | 69-WLBGA (4.52x2.92) |
