Step1: Product
ifm efector, inc. E11504
Images are for reference only
Manufacturer
Manufacturer No
E11504
Packaging
Box
Description
CONN RCPT MALE 4POS GOLD SCREW
Detailed Description
4 Position Circular Connector Receptacle, Male Pins Screw
Datasheet
Payment
Delivery
Mfr
ifm efector, inc.
Color
Black, Silver
Series
-
Features
Backshell
Packaging
Box
Shielding
Unshielded
Orientation
Keyed
Termination
Screw
Applications
-
Shell Finish
Nickel
Cable Opening
0.157" ~ 0.236" (4.00mm ~ 6.00mm)
Mounting Type
Free Hanging (In-Line)
Connector Type
Receptacle, Male Pins
Fastening Type
Threaded
Shell Material
Brass
Voltage Rating
45VAC, 70VDC
Insert Material
Polyamide (PA), Nylon
Shell Size, MIL
-
Contact Material
-
Mounting Feature
-
Primary Material
Metal
Ingress Protection
IP68 - Dust Tight, Waterproof
Number of Positions
4
Shell Size - Insert
M12-4
Current Rating (Amps)
4A
Operating Temperature
-25°C ~ 85°C
Contact Finish - Mating
Gold
Backshell Material, Plating
Polyamide (PA), Nylon
Material Flammability Rating
-
Contact Finish Thickness - Mating
-
| Attribute | Value |
|---|---|
| Mfr | ifm efector, inc. |
| Color | Black, Silver |
| Series | - |
| Features | Backshell |
| Packaging | Box |
| Shielding | Unshielded |
| Orientation | Keyed |
| Termination | Screw |
| Applications | - |
| Shell Finish | Nickel |
| Cable Opening | 0.157" ~ 0.236" (4.00mm ~ 6.00mm) |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Receptacle, Male Pins |
| Fastening Type | Threaded |
| Shell Material | Brass |
| Voltage Rating | 45VAC, 70VDC |
| Insert Material | Polyamide (PA), Nylon |
| Shell Size, MIL | - |
| Contact Material | - |
| Mounting Feature | - |
| Primary Material | Metal |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Number of Positions | 4 |
| Shell Size - Insert | M12-4 |
| Current Rating (Amps) | 4A |
| Operating Temperature | -25°C ~ 85°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | Polyamide (PA), Nylon |
| Material Flammability Rating | - |
| Contact Finish Thickness - Mating | - |
