Step1: Product
Grayhill Inc. 90HBJ05PRT
Images are for reference only
Manufacturer
Manufacturer No
90HBJ05PRT
Availability
In Stock
Packaging
Tape & Reel (TR)
Description
SWITCH DIP SLIDE SPST 25MA 24V
Detailed Description
Dip Switch SPST 5 Position Surface Mount Slide (Standard) Actuator 25mA 24VDC
Datasheet
Payment
Delivery
Pitch
0.100" (2.54mm), Full
Length
0.570" (14.48mm)
Series
90HB
Circuit
SPST
Features
Tape Seal
Washable
Yes
Packaging
Tape & Reel (TR)
Manufacturer
Grayhill Inc.
Actuator Type
Slide (Standard)
Body Material
Thermoplastic
Mounting Type
Surface Mount
Actuator Level
Flush, Recessed
Contact Finish
Gold
Voltage Rating
24VDC
Electrical Life
2,000 Cycles
Mechanical Life
2,000 Cycles
Contact Material
Copper Alloy
Termination Style
J Lead
Height Above Board
0.220" (5.59mm)
Base Product Number
90HBJ05
Number of Positions
5
Current Rating (Amps)
25mA
Operating Temperature
-40°C ~ 85°C
| Attribute | Value |
|---|---|
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.570" (14.48mm) |
| Series | 90HB |
| Circuit | SPST |
| Features | Tape Seal |
| Washable | Yes |
| Packaging | Tape & Reel (TR) |
| Manufacturer | Grayhill Inc. |
| Actuator Type | Slide (Standard) |
| Body Material | Thermoplastic |
| Mounting Type | Surface Mount |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 24VDC |
| Electrical Life | 2,000 Cycles |
| Mechanical Life | 2,000 Cycles |
| Contact Material | Copper Alloy |
| Termination Style | J Lead |
| Height Above Board | 0.220" (5.59mm) |
| Base Product Number | 90HBJ05 |
| Number of Positions | 5 |
| Current Rating (Amps) | 25mA |
| Operating Temperature | -40°C ~ 85°C |
