Step1: Product
GlobTek, Inc. G-1005B
Images are for reference only
Manufacturer
Manufacturer No
G-1005B
Availability
In Stock
Packaging
Bulk
Description
DC POWER JACK,2.5MM;PCB MOUNT
Detailed Description
Power Barrel Connector Jack 2.50mm ID (0.098"), 5.50mm OD (0.217") Through Hole, Right Angle
Datasheet
Payment
Delivery
Gender
Male
Series
-
Features
-
Includes
-
Packaging
Bulk
Shielding
Shielded
Body Color
-
Termination
Solder
Thread Size
-
Manufacturer
GlobTek, Inc.
Body Material
-
Mounting Type
Through Hole, Right Angle
Connector Type
Jack
Actual Diameter
0.098" (2.50mm ID), 0.217" (5.50mm OD)
Voltage - Rated
16VDC
Contact Material
Copper
Housing Material
Polybutylene Terephthalate (PBT), Glass Filled
Insulation Color
Black
Mounting Feature
-
Ingress Protection
-
Internal Switch(s)
Single Switch
Mating Length/Depth
-
Current Rating (Amps)
2 A
Operating Temperature
-
Contact Material - Plating
Nickel
Material Flammability Rating
-
Number of Positions/Contacts
2 Conductors, 3 Contacts
Industry Recognized Mating Diameter
2.50mm ID (0.098"), 5.50mm OD (0.217")
| Attribute | Value |
|---|---|
| Gender | Male |
| Series | - |
| Features | - |
| Includes | - |
| Packaging | Bulk |
| Shielding | Shielded |
| Body Color | - |
| Termination | Solder |
| Thread Size | - |
| Manufacturer | GlobTek, Inc. |
| Body Material | - |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Jack |
| Actual Diameter | 0.098" (2.50mm ID), 0.217" (5.50mm OD) |
| Voltage - Rated | 16VDC |
| Contact Material | Copper |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Insulation Color | Black |
| Mounting Feature | - |
| Ingress Protection | - |
| Internal Switch(s) | Single Switch |
| Mating Length/Depth | - |
| Current Rating (Amps) | 2 A |
| Operating Temperature | - |
| Contact Material - Plating | Nickel |
| Material Flammability Rating | - |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Industry Recognized Mating Diameter | 2.50mm ID (0.098"), 5.50mm OD (0.217") |
