Step1: Product
Espressif Systems ESP8684H2X
Images are for reference only
Manufacturer
Manufacturer No
ESP8684H2X
Date Code
25+
Quantity
6,000
Availability
In Stock
Package
24-VFQFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC RF TXRX+MCU BLE 24QFN
Detailed Description
IC RF TxRx + MCU Bluetooth, WiFi 802.11b/g/n, Bluetooth v5.0 2.402GHz ~ 2.48GHz, 2.412GHz ~ 2.484GHz 24-VFQFN Exposed Pad
Datasheet
Payment
Delivery
Mfr
Espressif Systems
GPIO
14
Type
TxRx + MCU
Series
ESP8684
Protocol
802.11b/g/n, Bluetooth v5.0
Frequency
2.402GHz ~ 2.48GHz, 2.412GHz ~ 2.484GHz
Packaging
Tape & Reel (TR); Cut Tape (CT)
Modulation
-
Memory Size
576KB ROM, 272KB SRAM
Sensitivity
-99dBm
Mounting Type
Surface Mount
Package / Case
24-VFQFN Exposed Pad
Power - Output
21.5dBm
Data Rate (Max)
72.2Mbps
Voltage - Supply
3V ~ 3.6V
Serial Interfaces
ADC, GPIO, I2C, I2S, PWM, SPI, UART
RF Family/Standard
Bluetooth, WiFi
Base Product Number
ESP8684
Current - Receiving
65mA
Operating Temperature
-40°C ~ 105°C
Current - Transmitting
300mA ~ 370mA
Supplier Device Package
24-QFN (4x4)
| Attribute | Value |
|---|---|
| Mfr | Espressif Systems |
| GPIO | 14 |
| Type | TxRx + MCU |
| Series | ESP8684 |
| Protocol | 802.11b/g/n, Bluetooth v5.0 |
| Frequency | 2.402GHz ~ 2.48GHz, 2.412GHz ~ 2.484GHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Modulation | - |
| Memory Size | 576KB ROM, 272KB SRAM |
| Sensitivity | -99dBm |
| Mounting Type | Surface Mount |
| Package / Case | 24-VFQFN Exposed Pad |
| Power - Output | 21.5dBm |
| Data Rate (Max) | 72.2Mbps |
| Voltage - Supply | 3V ~ 3.6V |
| Serial Interfaces | ADC, GPIO, I2C, I2S, PWM, SPI, UART |
| RF Family/Standard | Bluetooth, WiFi |
| Base Product Number | ESP8684 |
| Current - Receiving | 65mA |
| Operating Temperature | -40°C ~ 105°C |
| Current - Transmitting | 300mA ~ 370mA |
| Supplier Device Package | 24-QFN (4x4) |
