Encore Wire C8030.41.86

Images are for reference only

Manufacturer

Encore Wire

Manufacturer No

C8030.41.86

Packaging

Spool

Description

CABLE COAX PLEN RG-59 20AWG 100'

Detailed Description

Coaxial - Plenum Cable 20 AWG (0.52mm²) RG-59 100.0' (30.48m) 75 Ohms

Payment

Delivery

Usage

CCTV

Length

100.0' (30.48m)

Series

-

Features

18 AWG Unshielded Pair

Impedance

75 Ohms

Packaging

Spool

Cable Type

Coaxial - Plenum

Wire Gauge

20 AWG (0.52mm²)

Cable Group

RG-59

Shield Type

Braid

Jacket Color

Natural

Manufacturer

Encore Wire

Shield Coverage

95%

Shield Material

Copper, Bare

Conductor Strand

Solid

Conductor Material

Copper, Bare

Dielectric Diameter

0.135" (3.43mm)

Dielectric Material

Cellular (Foam) Polyethylene (Cellular FPE)

Operating Temperature

-

Jacket (Insulation) Diameter

0.200" (5.08mm)

Jacket (Insulation) Material

Poly-Vinyl Chloride (PVC)

VoP, Velocity of Propagation

83.0

Attribute	Value
Usage	CCTV
Length	100.0' (30.48m)
Series	-
Features	18 AWG Unshielded Pair
Impedance	75 Ohms
Packaging	Spool
Cable Type	Coaxial - Plenum
Wire Gauge	20 AWG (0.52mm²)
Cable Group	RG-59
Shield Type	Braid
Jacket Color	Natural
Manufacturer	Encore Wire
Shield Coverage	95%
Shield Material	Copper, Bare
Conductor Strand	Solid
Conductor Material	Copper, Bare
Dielectric Diameter	0.135" (3.43mm)
Dielectric Material	Cellular (Foam) Polyethylene (Cellular FPE)
Operating Temperature	-
Jacket (Insulation) Diameter	0.200" (5.08mm)
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
VoP, Velocity of Propagation	83.0
