Step1: Product
Eaton - Electronics Division CS-1050-R
Images are for reference only
Manufacturer
Manufacturer No
CS-1050-R
Packaging
Bulk
Description
CURR SENSE XFMR 10A T/H
Detailed Description
10 A Current Sense Transformer 20kHz ~ 200kHz 600mOhm 5.6 mH Through Hole
Datasheet
Payment
Delivery
Type
Non-Invasive (Solid Core)
Series
CS
Weight
-
Ratings
-
Packaging
Bulk
Inductance
5.6 mH
Manufacturer
Eaton - Electronics Division
Current Ratio
50:1
Mounting Type
Through Hole
ET (Volt-Time)
-
Frequency Range
20kHz ~ 200kHz
Size / Dimension
0.675" L x 0.375" W (17.15mm x 9.53mm)
Termination Style
PC Pin
DC Resistance (DCR)
600mOhm
Current Rating (Amps)
10 A
Height - Seated (Max)
0.800" (20.32mm)
Turns Ratio - Primary:Secondary
-
| Attribute | Value |
|---|---|
| Type | Non-Invasive (Solid Core) |
| Series | CS |
| Weight | - |
| Ratings | - |
| Packaging | Bulk |
| Inductance | 5.6 mH |
| Manufacturer | Eaton - Electronics Division |
| Current Ratio | 50:1 |
| Mounting Type | Through Hole |
| ET (Volt-Time) | - |
| Frequency Range | 20kHz ~ 200kHz |
| Size / Dimension | 0.675" L x 0.375" W (17.15mm x 9.53mm) |
| Termination Style | PC Pin |
| DC Resistance (DCR) | 600mOhm |
| Current Rating (Amps) | 10 A |
| Height - Seated (Max) | 0.800" (20.32mm) |
| Turns Ratio - Primary:Secondary | - |
