Step1: Product
EAO 09-0A22.1111
Images are for reference only
Manufacturer
Manufacturer No
09-0A22.1111
Packaging
Box
Description
SWITCH KEYPAD 6KEY 0.03A 32V
Detailed Description
Keypad Switch 6 Keys Snap Dome Contacts Matrix Output Illuminated - White 0.03A @ 32VDC
Datasheet
Payment
Delivery
Legend
-
Series
09
Features
-
Key Type
-
Key Color
Black
Packaging
Box
Legend Type
Fixed
Output Type
Matrix
Switch Type
Snap Dome
Illumination
Illuminated - White
Legend Color
White
Manufacturer
EAO
Mounting Type
Panel Mount, Front
Number of Keys
6
Approval Agency
-
Operational Life
250,000 Cycles
Termination Style
Cable with Connector
Ingress Protection
IP67 - Dust Tight, Waterproof
Operating Temperature
-40°C ~ 85°C
Matrix (Columns x Rows)
3 x 2
Panel Cutout Dimensions
Rectangular - 107.10mm x 68.80mm
Contact Rating @ Voltage
0.03A @ 32VDC
Illumination Voltage (Nominal)
-
| Attribute | Value |
|---|---|
| Legend | - |
| Series | 09 |
| Features | - |
| Key Type | - |
| Key Color | Black |
| Packaging | Box |
| Legend Type | Fixed |
| Output Type | Matrix |
| Switch Type | Snap Dome |
| Illumination | Illuminated - White |
| Legend Color | White |
| Manufacturer | EAO |
| Mounting Type | Panel Mount, Front |
| Number of Keys | 6 |
| Approval Agency | - |
| Operational Life | 250,000 Cycles |
| Termination Style | Cable with Connector |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Operating Temperature | -40°C ~ 85°C |
| Matrix (Columns x Rows) | 3 x 2 |
| Panel Cutout Dimensions | Rectangular - 107.10mm x 68.80mm |
| Contact Rating @ Voltage | 0.03A @ 32VDC |
| Illumination Voltage (Nominal) | - |
