Step1: Product
Diodes Incorporated BAW56-7-F
Images are for reference only
Manufacturer
Manufacturer No
BAW56-7-F
Date Code
19+
Quantity
200
Availability
In Stock
Package
TO-236-3, SC-59, SOT-23-3
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
DIODE ARRAY GP 75V 300MA SOT23-3
Detailed Description
Diode Array 1 Pair Common Anode 75 V 300mA (DC) Surface Mount TO-236-3, SC-59, SOT-23-3
Datasheet
Payment
Delivery
Speed
Fast Recovery =< 500ns, > 200mA (Io)
Series
-
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
Standard
Manufacturer
Diodes Incorporated
Mounting Type
Surface Mount
Package / Case
TO-236-3, SC-59, SOT-23-3
Base Product Number
BAW56
Diode Configuration
1 Pair Common Anode
Supplier Device Package
SOT-23-3
Reverse Recovery Time (trr)
4 ns
Current - Reverse Leakage @ Vr
2.5 µA @ 75 V
Voltage - DC Reverse (Vr) (Max)
75 V
Operating Temperature - Junction
-65°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If
1.25 V @ 150 mA
Current - Average Rectified (Io) (per Diode)
300mA (DC)
| Attribute | Value |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Series | - |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | Standard |
| Manufacturer | Diodes Incorporated |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number | BAW56 |
| Diode Configuration | 1 Pair Common Anode |
| Supplier Device Package | SOT-23-3 |
| Reverse Recovery Time (trr) | 4 ns |
| Current - Reverse Leakage @ Vr | 2.5 µA @ 75 V |
| Voltage - DC Reverse (Vr) (Max) | 75 V |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 1.25 V @ 150 mA |
| Current - Average Rectified (Io) (per Diode) | 300mA (DC) |
