Step1: Product
Delta Electronics/Components 1008HS-273EKFS
Images are for reference only
Manufacturer
Manufacturer No
1008HS-273EKFS
Package
1008 (2520 Metric)
Packaging
Tape & Reel (TR)
Description
FIXED IND 27UH 180MA 3.5 OHM SMD
Detailed Description
27 µH Unshielded Drum Core, Wirewound Inductor 180 mA 3.5Ohm 1008 (2520 Metric)
Datasheet
Payment
Delivery
Mfr
Delta Electronics/Components
Type
Drum Core, Wirewound
Series
1008HS
Ratings
-
Features
-
Q @ Freq
20 @ 2.52MHz
Packaging
Tape & Reel (TR)
Shielding
Unshielded
Tolerance
±10%
Inductance
27 µH
Mounting Type
Surface Mount
Package / Case
1008 (2520 Metric)
Material - Core
Ferrite
Size / Dimension
0.115" L x 0.110" W (2.92mm x 2.79mm)
DC Resistance (DCR)
3.5Ohm
Current Rating (Amps)
180 mA
Height - Seated (Max)
0.083" (2.10mm)
Operating Temperature
-40°C ~ 85°C
Supplier Device Package
1008
Frequency - Self Resonant
17MHz
Current - Saturation (Isat)
-
Inductance Frequency - Test
2.52 MHz
| Attribute | Value |
|---|---|
| Mfr | Delta Electronics/Components |
| Type | Drum Core, Wirewound |
| Series | 1008HS |
| Ratings | - |
| Features | - |
| Q @ Freq | 20 @ 2.52MHz |
| Packaging | Tape & Reel (TR) |
| Shielding | Unshielded |
| Tolerance | ±10% |
| Inductance | 27 µH |
| Mounting Type | Surface Mount |
| Package / Case | 1008 (2520 Metric) |
| Material - Core | Ferrite |
| Size / Dimension | 0.115" L x 0.110" W (2.92mm x 2.79mm) |
| DC Resistance (DCR) | 3.5Ohm |
| Current Rating (Amps) | 180 mA |
| Height - Seated (Max) | 0.083" (2.10mm) |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 1008 |
| Frequency - Self Resonant | 17MHz |
| Current - Saturation (Isat) | - |
| Inductance Frequency - Test | 2.52 MHz |
