Step1: Product
CoolCAD CC3380354L
Images are for reference only
Manufacturer
Manufacturer No
CC3380354L
Package
TO-247-4L
Packaging
Bulk
Description
3300V 70mOhm SiC MOSFET
Detailed Description
N-Channel 3300 V 40A 210W (Ta) Through Hole TO-247-4L
Datasheet
Payment
Delivery
Mfr
CoolCAD
Grade
-
Series
C233
FET Type
N-Channel
Packaging
Bulk
Vgs (Max)
+20V, -5V
Technology
SiCFET (Silicon Carbide)
Mounting Type
Through Hole
Qualification
-
Package / Case
TO-247-4L
Vgs(th) (Max) @ Id
2.98V @ 20mA
Operating Temperature
-65°C ~ 195°C (TA)
Rds On (Max) @ Id, Vgs
75mOhm @ 40A, 20V
Power Dissipation (Max)
210W (Ta)
Supplier Device Package
TO-247-4L
Gate Charge (Qg) (Max) @ Vgs
220 nC @ 20 V
Drain to Source Voltage (Vdss)
3300 V
Input Capacitance (Ciss) (Max) @ Vds
2700 pF @ 1000 V
Drive Voltage (Max Rds On, Min Rds On)
15V, 20V
Current - Continuous Drain (Id) @ 25°C
40A
| Attribute | Value |
|---|---|
| Mfr | CoolCAD |
| Grade | - |
| Series | C233 |
| FET Type | N-Channel |
| Packaging | Bulk |
| Vgs (Max) | +20V, -5V |
| Technology | SiCFET (Silicon Carbide) |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-247-4L |
| Vgs(th) (Max) @ Id | 2.98V @ 20mA |
| Operating Temperature | -65°C ~ 195°C (TA) |
| Rds On (Max) @ Id, Vgs | 75mOhm @ 40A, 20V |
| Power Dissipation (Max) | 210W (Ta) |
| Supplier Device Package | TO-247-4L |
| Gate Charge (Qg) (Max) @ Vgs | 220 nC @ 20 V |
| Drain to Source Voltage (Vdss) | 3300 V |
| Input Capacitance (Ciss) (Max) @ Vds | 2700 pF @ 1000 V |
| Drive Voltage (Max Rds On, Min Rds On) | 15V, 20V |
| Current - Continuous Drain (Id) @ 25°C | 40A |
