Step1: Product
Coilcraft DA2304-ALD
Images are for reference only
Manufacturer
Manufacturer No
DA2304-ALD
Date Code
25+
Quantity
5,000
Availability
In Stock
Packaging
Strip
Description
PWR XFMR 7.2VA CHAS MT
Detailed Description
7.2VA Power Transformer 3.3V Primary 6V Secondary Chassis Mount
Datasheet
Payment
Delivery
Series
DA2304
Packaging
Strip
Center Tap
No
Power - Max
7.2VA
Manufacturer
Coilcraft
Mounting Type
Chassis Mount
Size / Dimension
10.30mm L x 8.10mm W
Termination Style
Solder, Quick Connect
Voltage - Primary
3.3V
Primary Winding(s)
Dual
Voltage - Isolation
2500Vrms
Secondary Winding(s)
Dual
Height - Seated (Max)
5.97mm
Current - Output (Max)
-
Voltage - Secondary (Full Load)
6V
| Attribute | Value |
|---|---|
| Series | DA2304 |
| Packaging | Strip |
| Center Tap | No |
| Power - Max | 7.2VA |
| Manufacturer | Coilcraft |
| Mounting Type | Chassis Mount |
| Size / Dimension | 10.30mm L x 8.10mm W |
| Termination Style | Solder, Quick Connect |
| Voltage - Primary | 3.3V |
| Primary Winding(s) | Dual |
| Voltage - Isolation | 2500Vrms |
| Secondary Winding(s) | Dual |
| Height - Seated (Max) | 5.97mm |
| Current - Output (Max) | - |
| Voltage - Secondary (Full Load) | 6V |
