Cinch Connectivity Solutions AIM-Cambridge CP1094-U
Images are for reference only
Manufacturer
Manufacturer No
CP1094-U
Availability
In Stock
Packaging
Bulk
Description
CONN BNC JACK STR 50 OHM SOLDER
Detailed Description
BNC Connector Jack, Female Socket 50 Ohms Panel Mount Solder Cup
Datasheet
Payment
Delivery
Mfr
Cinch Connectivity Solutions AIM-Cambridge
Series
-
Features
Extended Insulation
Includes
3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
Impedance
50 Ohms
Packaging
Bulk
Body Finish
Nickel
Cable Group
-
Body Material
Brass
Housing Color
Silver
Mating Cycles
500
Mounting Type
Panel Mount
Connector Type
Jack, Female Socket
Fastening Type
Bayonet Lock
Insertion Loss
-
Voltage Rating
500 V
Connector Style
BNC
Frequency - Max
4 GHz
Number of Ports
1
Mounting Feature
Bulkhead - Rear Side Nut
Ingress Protection
-
Shield Termination
Solder
Base Product Number
CP1094
Contact Termination
Solder Cup
Dielectric Material
Polytetrafluoroethylene (PTFE)
Operating Temperature
-55°C ~ 85°C
Center Contact Plating
Gold
Center Contact Material
Beryllium Copper
| Attribute | Value |
|---|---|
| Mfr | Cinch Connectivity Solutions AIM-Cambridge |
| Series | - |
| Features | Extended Insulation |
| Includes | 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut |
| Impedance | 50 Ohms |
| Packaging | Bulk |
| Body Finish | Nickel |
| Cable Group | - |
| Body Material | Brass |
| Housing Color | Silver |
| Mating Cycles | 500 |
| Mounting Type | Panel Mount |
| Connector Type | Jack, Female Socket |
| Fastening Type | Bayonet Lock |
| Insertion Loss | - |
| Voltage Rating | 500 V |
| Connector Style | BNC |
| Frequency - Max | 4 GHz |
| Number of Ports | 1 |
| Mounting Feature | Bulkhead - Rear Side Nut |
| Ingress Protection | - |
| Shield Termination | Solder |
| Base Product Number | CP1094 |
| Contact Termination | Solder Cup |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -55°C ~ 85°C |
| Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper |
