Step1: Product
Bourns Inc. MF-SMDF050-2
Images are for reference only
Manufacturer
Manufacturer No
MF-SMDF050-2
Date Code
11+
Quantity
643
Availability
In Stock
Package
2018 (5045 Metric), Concave
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
PTC RESET FUSE 60V 550MA 2018
Detailed Description
Polymeric PTC Resettable Fuse 60V 550 mA Ih Surface Mount 2018 (5045 Metric), Concave
Datasheet
Payment
Delivery
Type
Polymeric
Series
Multifuse®, MF-SMDF
Ratings
-
Packaging
Tape & Reel (TR); Cut Tape (CT)
Lead Spacing
-
Manufacturer
Bourns Inc.
Time to Trip
3 s
Current - Max
10 A
Mounting Type
Surface Mount
Voltage - Max
60V
Package / Case
2018 (5045 Metric), Concave
Approval Agency
cURus, TUV
Thickness (Max)
0.043" (1.09mm)
Size / Dimension
0.200" L x 0.180" W (5.08mm x 4.58mm)
Base Product Number
MF-SMDF
Current - Trip (It)
1.2 A
Height - Seated (Max)
-
Operating Temperature
-40°C ~ 85°C
Current - Hold (Ih) (Max)
550 mA
Resistance - Initial (Ri) (Min)
200 mOhms
Resistance - Post Trip (R1) (Max)
1 Ohms
| Attribute | Value |
|---|---|
| Type | Polymeric |
| Series | Multifuse®, MF-SMDF |
| Ratings | - |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Lead Spacing | - |
| Manufacturer | Bourns Inc. |
| Time to Trip | 3 s |
| Current - Max | 10 A |
| Mounting Type | Surface Mount |
| Voltage - Max | 60V |
| Package / Case | 2018 (5045 Metric), Concave |
| Approval Agency | cURus, TUV |
| Thickness (Max) | 0.043" (1.09mm) |
| Size / Dimension | 0.200" L x 0.180" W (5.08mm x 4.58mm) |
| Base Product Number | MF-SMDF |
| Current - Trip (It) | 1.2 A |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 550 mA |
| Resistance - Initial (Ri) (Min) | 200 mOhms |
| Resistance - Post Trip (R1) (Max) | 1 Ohms |
