Analog Devices Inc./Maxim Integrated TMC6200-TA-T
Images are for reference only
Manufacturer
Manufacturer No
TMC6200-TA-T
Quantity
60
Availability
In Stock
Package
48-TQFP Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC GATE DRVR HALF-BRIDGE 48TQFP
Detailed Description
Half-Bridge Gate Driver IC CMOS 48-TQFP-EP (7x7)
Datasheet
Payment
Delivery
Series
-
Gate Type
MOSFET (N-Channel)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Input Type
CMOS
Channel Type
3-Phase
Manufacturer
Analog Devices Inc./Maxim Integrated
Mounting Type
Surface Mount
Package / Case
48-TQFP Exposed Pad
Voltage - Supply
10V ~ 60V
Number of Drivers
6
Base Product Number
TMC6200
DigiKey Programmable
Not Verified
Driven Configuration
Half-Bridge
Operating Temperature
-40°C ~ 125°C (TJ)
Rise / Fall Time (Typ)
20ns, 20ns
Supplier Device Package
48-TQFP-EP (7x7)
Logic Voltage - VIL, VIH
-
High Side Voltage - Max (Bootstrap)
85 V
Current - Peak Output (Source, Sink)
1.5A, 1.5A
| Attribute | Value |
|---|---|
| Series | - |
| Gate Type | MOSFET (N-Channel) |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Input Type | CMOS |
| Channel Type | 3-Phase |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Mounting Type | Surface Mount |
| Package / Case | 48-TQFP Exposed Pad |
| Voltage - Supply | 10V ~ 60V |
| Number of Drivers | 6 |
| Base Product Number | TMC6200 |
| DigiKey Programmable | Not Verified |
| Driven Configuration | Half-Bridge |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Rise / Fall Time (Typ) | 20ns, 20ns |
| Supplier Device Package | 48-TQFP-EP (7x7) |
| Logic Voltage - VIL, VIH | - |
| High Side Voltage - Max (Bootstrap) | 85 V |
| Current - Peak Output (Source, Sink) | 1.5A, 1.5A |
