Analog Devices Inc./Maxim Integrated TMC5160A-TA-T
Images are for reference only
Manufacturer
Manufacturer No
TMC5160A-TA-T
Quantity
8,320
Availability
In Stock
Package
48-TQFP Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC MTR DRVR BIPOLAR 8-60V 48TQFP
Detailed Description
Bipolar Motor Driver Power MOSFET SPI, Step/Direction 48-TQFP-EP (7x7)
Datasheet
Payment
Delivery
Series
-
Function
Driver - Fully Integrated, Control and Power Stage
Interface
SPI, Step/Direction
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
Power MOSFET
Applications
Automation Control, Industrial, Medical
Manufacturer
Analog Devices Inc./Maxim Integrated
Mounting Type
Surface Mount
Package / Case
48-TQFP Exposed Pad
Voltage - Load
10V ~ 55V
Step Resolution
1 ~ 1/256
Current - Output
20A
Voltage - Supply
10V ~ 50V
Base Product Number
TMC5160
Motor Type - AC, DC
Universal
Motor Type - Stepper
Bipolar
Output Configuration
Half Bridge (4)
Operating Temperature
-40°C ~ 125°C (TJ)
Supplier Device Package
48-TQFP-EP (7x7)
| Attribute | Value |
|---|---|
| Series | - |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Interface | SPI, Step/Direction |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | Power MOSFET |
| Applications | Automation Control, Industrial, Medical |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Mounting Type | Surface Mount |
| Package / Case | 48-TQFP Exposed Pad |
| Voltage - Load | 10V ~ 55V |
| Step Resolution | 1 ~ 1/256 |
| Current - Output | 20A |
| Voltage - Supply | 10V ~ 50V |
| Base Product Number | TMC5160 |
| Motor Type - AC, DC | Universal |
| Motor Type - Stepper | Bipolar |
| Output Configuration | Half Bridge (4) |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Supplier Device Package | 48-TQFP-EP (7x7) |
