Step1: Product
Amphenol Positronic DF10M4BN/AA
Images are for reference only
Manufacturer
Manufacturer No
DF10M4BN/AA
Packaging
Bulk
Description
HEADER
Detailed Description
Connector Header Through Hole, Right Angle 10 position
Datasheet
Payment
Delivery
Mfr
Amphenol Positronic
Style
Board to Board or Cable
Series
DF
Features
-
Packaging
Bulk
Shrouding
Shrouded - 4 Wall
Termination
Solder
Applications
General Purpose
Contact Type
Male Pin
Contact Shape
Circular
Mounting Type
Through Hole, Right Angle
Connector Type
Header
Fastening Type
Latch Holder
Number of Rows
2
Pitch - Mating
-
Voltage Rating
500V
Contact Material
Copper Alloy
Insulation Color
Black, Green
Insulation Height
-
Ingress Protection
-
Insulation Material
Polyamide (PA), Nylon
Number of Positions
10
Row Spacing - Mating
-
Contact Finish - Post
-
Contact Length - Post
-
Current Rating (Amps)
-
Operating Temperature
-55°C ~ 125°C
Mated Stacking Heights
-
Overall Contact Length
-
Contact Finish - Mating
Gold
Contact Length - Mating
-
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
-
Contact Finish Thickness - Mating
Flash
| Attribute | Value |
|---|---|
| Mfr | Amphenol Positronic |
| Style | Board to Board or Cable |
| Series | DF |
| Features | - |
| Packaging | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact Type | Male Pin |
| Contact Shape | Circular |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Header |
| Fastening Type | Latch Holder |
| Number of Rows | 2 |
| Pitch - Mating | - |
| Voltage Rating | 500V |
| Contact Material | Copper Alloy |
| Insulation Color | Black, Green |
| Insulation Height | - |
| Ingress Protection | - |
| Insulation Material | Polyamide (PA), Nylon |
| Number of Positions | 10 |
| Row Spacing - Mating | - |
| Contact Finish - Post | - |
| Contact Length - Post | - |
| Current Rating (Amps) | - |
| Operating Temperature | -55°C ~ 125°C |
| Mated Stacking Heights | - |
| Overall Contact Length | - |
| Contact Finish - Mating | Gold |
| Contact Length - Mating | - |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | Flash |
