Step1: Product
Amphenol PCD M24308/24-11F
Images are for reference only
Manufacturer
Manufacturer No
M24308/24-11F
Availability
In Stock
Packaging
Retail Package
Description
CONN D-SUB PLG 50POS PNL MT SLDR
Detailed Description
50 Position D-Sub Plug, Male Pins Connector
Payment
Delivery
Mfr
Amphenol PCD
Color
Black
Series
Military, MIL-DTL-24308
Features
-
Packaging
Retail Package
Wire Gauge
-
Termination
Solder
Contact Form
-
Contact Type
Signal
Mounting Type
Panel Mount, Through Hole
Connector Type
Plug, Male Pins
Contact Finish
Gold
Flange Feature
Housing/Shell (Unthreaded)
Number of Rows
3
Voltage Rating
1700V
Backset Spacing
-
Connector Style
D-Sub
Contact Material
Copper Alloy
Ingress Protection
-
Dielectric Material
Polycyclohexylenedimethylene Terephthalate (PCT)
Number of Positions
50
Current Rating (Amps)
7.5A
Operating Temperature
-55°C ~ 150°C
Shell Material, Finish
Steel, Yellow Chromate Plated Cadmium
Contact Finish Thickness
50.0µin (1.27µm)
Material Flammability Rating
UL94 V-0
Shell Size, Connector Layout
5 (DD, D)
| Attribute | Value |
|---|---|
| Mfr | Amphenol PCD |
| Color | Black |
| Series | Military, MIL-DTL-24308 |
| Features | - |
| Packaging | Retail Package |
| Wire Gauge | - |
| Termination | Solder |
| Contact Form | - |
| Contact Type | Signal |
| Mounting Type | Panel Mount, Through Hole |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (Unthreaded) |
| Number of Rows | 3 |
| Voltage Rating | 1700V |
| Backset Spacing | - |
| Connector Style | D-Sub |
| Contact Material | Copper Alloy |
| Ingress Protection | - |
| Dielectric Material | Polycyclohexylenedimethylene Terephthalate (PCT) |
| Number of Positions | 50 |
| Current Rating (Amps) | 7.5A |
| Operating Temperature | -55°C ~ 150°C |
| Shell Material, Finish | Steel, Yellow Chromate Plated Cadmium |
| Contact Finish Thickness | 50.0µin (1.27µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 5 (DD, D) |
