Step1: Product
American Zettler AZ2800-2A-24DE
Images are for reference only
Manufacturer
Manufacturer No
AZ2800-2A-24DE
Packaging
Tray
Description
RELAY EV CHG SOLAR DPST 40A 24V
Detailed Description
General Purpose Relay DPST-NO (2 Form A) 24VDC Coil Chassis Mount
Datasheet
Payment
Delivery
Mfr
American Zettler
Grade
-
Series
AZ2800
Features
-
Coil Type
Non Latching
Packaging
Tray
Relay Type
General Purpose
Seal Rating
Sealed - Fully
Coil Current
68.5 mA
Coil Voltage
24VDC
Contact Form
DPST-NO (2 Form A)
Operate Time
25 ms
Release Time
25 ms
Mounting Type
Chassis Mount
Qualification
-
Approval Agency
CUR, UL, VDE
Coil Insulation
Class F
Coil Resistance
350 Ohms
Contact Material
Silver Cadmium Oxide (AgCdO)
Switching Voltage
600VAC, 30VDC - Max
Termination Style
Quick Connect - 0.250" (6.3mm)
Base Product Number
AZ2800-2A
Load - Max Switching
11080VA, 1200W
Must Operate Voltage
18 VDC
Must Release Voltage
2.4 VDC
Operating Temperature
-40°C ~ 85°C
Contact Rating (Current)
40 A
| Attribute | Value |
|---|---|
| Mfr | American Zettler |
| Grade | - |
| Series | AZ2800 |
| Features | - |
| Coil Type | Non Latching |
| Packaging | Tray |
| Relay Type | General Purpose |
| Seal Rating | Sealed - Fully |
| Coil Current | 68.5 mA |
| Coil Voltage | 24VDC |
| Contact Form | DPST-NO (2 Form A) |
| Operate Time | 25 ms |
| Release Time | 25 ms |
| Mounting Type | Chassis Mount |
| Qualification | - |
| Approval Agency | CUR, UL, VDE |
| Coil Insulation | Class F |
| Coil Resistance | 350 Ohms |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Switching Voltage | 600VAC, 30VDC - Max |
| Termination Style | Quick Connect - 0.250" (6.3mm) |
| Base Product Number | AZ2800-2A |
| Load - Max Switching | 11080VA, 1200W |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2.4 VDC |
| Operating Temperature | -40°C ~ 85°C |
| Contact Rating (Current) | 40 A |
