Step1: Product
American Bright Optoelectronics Corporation BL-HJEGE36H-TRB
Images are for reference only
Manufacturer
Manufacturer No
BL-HJEGE36H-TRB
Package
0605 (1613 Metric)
Packaging
Bulk
Description
LED ORG-RED/YL-GRN CLR 0605 SMD
Detailed Description
Orange-Red, Yellow-Green 620nm Orange-Red, 570nm Yellow-Green LED Indication - Discrete 2V Orange-Red, 2V Yellow-Green 0605 (1613 Metric)
Datasheet
Payment
Delivery
Mfr
American Bright Optoelectronics Corporation
Color
Orange-Red, Yellow-Green
Series
-
Features
-
Lens Size
1.25mm x 1.00mm
Packaging
Bulk
Lens Color
Colorless
Lens Style
Rectangle with Flat Top
Height (Max)
0.50mm
Configuration
Independent
Mounting Type
Surface Mount
Viewing Angle
120°
Current - Test
20mA Orange-Red, 20mA Yellow-Green
Package / Case
0605 (1613 Metric)
Size / Dimension
1.60mm L x 1.25mm W
Lens Transparency
Clear
Wavelength - Peak
630nm Orange-Red, 570nm Yellow-Green
Millicandela Rating
70mcd Orange-Red, 30mcd Yellow-Green
Wavelength - Dominant
620nm Orange-Red, 570nm Yellow-Green
Supplier Device Package
0605
Voltage - Forward (Vf) (Typ)
2V Orange-Red, 2V Yellow-Green
| Attribute | Value |
|---|---|
| Mfr | American Bright Optoelectronics Corporation |
| Color | Orange-Red, Yellow-Green |
| Series | - |
| Features | - |
| Lens Size | 1.25mm x 1.00mm |
| Packaging | Bulk |
| Lens Color | Colorless |
| Lens Style | Rectangle with Flat Top |
| Height (Max) | 0.50mm |
| Configuration | Independent |
| Mounting Type | Surface Mount |
| Viewing Angle | 120° |
| Current - Test | 20mA Orange-Red, 20mA Yellow-Green |
| Package / Case | 0605 (1613 Metric) |
| Size / Dimension | 1.60mm L x 1.25mm W |
| Lens Transparency | Clear |
| Wavelength - Peak | 630nm Orange-Red, 570nm Yellow-Green |
| Millicandela Rating | 70mcd Orange-Red, 30mcd Yellow-Green |
| Wavelength - Dominant | 620nm Orange-Red, 570nm Yellow-Green |
| Supplier Device Package | 0605 |
| Voltage - Forward (Vf) (Typ) | 2V Orange-Red, 2V Yellow-Green |
