Allegro MicroSystems AMT49502KLPTR-5
Images are for reference only
Manufacturer
Manufacturer No
AMT49502KLPTR-5
Quantity
30
Availability
In Stock
Package
24-TSSOP (0.173", 4.40mm Width) Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC HALF BRIDGE DRVR 2.1A 24TSSOP
Detailed Description
Half Bridge Driver DC Motors, Solenoids Power MOSFET 24-TSSOP-EP
Datasheet
Payment
Delivery
Grade
Automotive
Series
-
Features
Charge Pump, Status Flag
Interface
Analog, PWM, Serial, SPI
Load Type
Inductive, Capacitive, Resistive
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
Power MOSFET
Applications
DC Motors, Solenoids
Manufacturer
Allegro MicroSystems
Rds On (Typ)
2.8Ohm LS (Max), 13.9Ohm HS (Max)
Mounting Type
Surface Mount
Qualification
AEC-Q100
Package / Case
24-TSSOP (0.173", 4.40mm Width) Exposed Pad
Voltage - Load
5.5V ~ 80V
Fault Protection
Current Limiting, Over Current, Over Temperature
Voltage - Supply
5.5V ~ 80V
Base Product Number
AMT49502
Output Configuration
Half Bridge
Current - Peak Output
2.1A
Operating Temperature
165°C (TJ)
Supplier Device Package
24-TSSOP-EP
Current - Output / Channel
2.1A
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Series | - |
| Features | Charge Pump, Status Flag |
| Interface | Analog, PWM, Serial, SPI |
| Load Type | Inductive, Capacitive, Resistive |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | Power MOSFET |
| Applications | DC Motors, Solenoids |
| Manufacturer | Allegro MicroSystems |
| Rds On (Typ) | 2.8Ohm LS (Max), 13.9Ohm HS (Max) |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Voltage - Load | 5.5V ~ 80V |
| Fault Protection | Current Limiting, Over Current, Over Temperature |
| Voltage - Supply | 5.5V ~ 80V |
| Base Product Number | AMT49502 |
| Output Configuration | Half Bridge |
| Current - Peak Output | 2.1A |
| Operating Temperature | 165°C (TJ) |
| Supplier Device Package | 24-TSSOP-EP |
| Current - Output / Channel | 2.1A |
