Step1: Product
Adam Tech ASP-2.5.-S-SR
Images are for reference only
Manufacturer
Manufacturer No
ASP-2.5.-S-SR
Packaging
Bag
Description
CONN PLUG STEREO 2.5MM 3COND
Detailed Description
2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone Phone Plug Stereo (3 Conductor, TRS) Connector Solder Eyelet(s)
Datasheet
Payment
Delivery
Mfr
Adam Tech
Gender
Male
Series
ASP
Features
Strain Relief
Includes
2 pcs - 1 Connector, 1 Handle
Packaging
Bag
Shielding
Unshielded
Body Color
Silver, Black
Termination
Solder Eyelet(s)
Thread Size
-
Signal Lines
Stereo (3 Conductor, TRS)
Body Material
Brass
Cable Opening
0.181" (4.60mm)
Mounting Type
Free Hanging (In-Line)
Connector Type
Phone Plug
Actual Diameter
0.098" (2.50mm)
Panel Hole Size
-
Voltage - Rated
-
Contact Material
Brass
Housing Material
Polyethylene (PE)
Insulation Color
Black
Internal Switch(s)
Does Not Contain Switch
Base Product Number
ASP-2.5
Mating Length/Depth
0.433" (11.00mm)
Operating Temperature
-
Contact Material - Plating
Nickel
Number of Positions/Contacts
3 Conductors, 3 Contacts
Industry Recognized Mating Diameter
2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone
| Attribute | Value |
|---|---|
| Mfr | Adam Tech |
| Gender | Male |
| Series | ASP |
| Features | Strain Relief |
| Includes | 2 pcs - 1 Connector, 1 Handle |
| Packaging | Bag |
| Shielding | Unshielded |
| Body Color | Silver, Black |
| Termination | Solder Eyelet(s) |
| Thread Size | - |
| Signal Lines | Stereo (3 Conductor, TRS) |
| Body Material | Brass |
| Cable Opening | 0.181" (4.60mm) |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Phone Plug |
| Actual Diameter | 0.098" (2.50mm) |
| Panel Hole Size | - |
| Voltage - Rated | - |
| Contact Material | Brass |
| Housing Material | Polyethylene (PE) |
| Insulation Color | Black |
| Internal Switch(s) | Does Not Contain Switch |
| Base Product Number | ASP-2.5 |
| Mating Length/Depth | 0.433" (11.00mm) |
| Operating Temperature | - |
| Contact Material - Plating | Nickel |
| Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Industry Recognized Mating Diameter | 2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone |
